1285813 CABLE, COAX, RG178B/U, 50M
Κατασκευαστής: LAPP KABEL
Part Number:2170002

Product Image
CABLE, COAX, RG178B/U, 50M; Coaxial Cable Type:RG178; Wire Gauge:30AWG; Conductor Area CSA:0.055mm?; Impedance:50ohm; Reel Length (Imperial):164ft; Reel Length (Metric):50m; Jacket Colour:Brown; Jacket Material:FEP; Conductor Material:Copper; No. of Max Strands x Strand Size:7 x 0.1mm; External Diameter:1.9mm; Product Range:-; SVHC:No SVHC (15-Jan-2019); Attenuation @ 100MHz:43dB; Attenuation @ 10MHz:20dB; Attenuation @ 1GHz:153dB; Attenuation @ 1MHz:8dB; Attenuation @ 200MHz:63dB; Attenuation @ 400MHz:93dB; Attenuation @ 50MHz:32dB; Attenuation @ 800MHz:134dB; Coaxial Type:RG178; Conductor Make-up:7 / 0.1mm; Inner Conductor Diameter:0.3mm; Nominal Capacitance:95pF/m; Operating Temperature Max:205?C; Operating Temperature Min:-190?C; Outer Diameter:1.9mm; Velocity of Propagation (%):70%



RoHS: Όχι

Δεν μπορώ να προσθέσω στο καλάθι διότι δεν υπάρχει απόθεμα
Στείλτε email σε ένα φίλο
Βάλτε το στα υπ΄όψιν


Volume Pricing
Quantity Price
1-4 € 255.66
5-9 € 247.17
10+ € 229.7
Minimum Order 1
Maximum Order
Order Multiple 1
Unit Price € 255.66
Pack Size 1
